Can a USB Type-C display adapter support an e Pin?
A USB Type-C to DP/mDP 4 lane display adapter support only E pin configuration and A USB Type-C to HDMI/VGA/DVI 4 lane display adapter support only C pin configuration. Cypress provides FW and configuration files for supporting pin assignments C, E and C+E.
What do you need to know about USB Type C?
USB TYPE-C Connector. USB TYPE-C Connector Pinout [Click the image to enlarge it] USB TYPE-C is a new port designed for high speed data exchange and high power deliver capability. The first thing to realize is that USB TYPE-C is not a new USB standard like USB1.0, USB2.0, USB3.0 and USB3.1. Those are protocols defining speed and other features ...
How many pins does a USB Type C connector have?
The USB Type-C connector has 24 pins. Figures 1 and 2, respectively, show the pins for the USB Type-C receptacle and plug. Figure 1. The USB Type-C receptacle. Image courtesy of Microchip. Figure 2. The USB Type-C plug. Image courtesy of Microchip. The D+ and D- pins are the differential pairs used for the USB 2.0 connectivity.
How to assign a pin to a USB adapter?
Cypress provides FW and configuration files for supporting pin assignments C, E and C+E. Cypress’s EZ-PD Configuration Utility can be used to program parts with the right firmware and configuration settings. Please refer to KBA203802 for steps on configuring the pin assignment on the USB Type-C connector based on your adapter.
